Display Format Native Resolution

4K UHD (3840 × 2160) ADS

Panel Type

D-LED

Aspect Ratio

16:09

Picture Response Time

8ms (typ.)

Refresh Frequency

60Hz

Display Colors

1.07B (8bit+FRC)

Brightness (typical)

450cd/m²(typ.)

Contrast Ratio

1200:1 (typ.)

Viewing Angle

178°(H)/178°(V)

Life Time

50000 Hours (Expected)

Others

Bonding Technology: The gap between tempered glass and screen is close to 0

Touch Point

Up to 50 Multi-touch points

Touch Response Time

Single touch: ≤ 3ms
Multiple touch: ≤3 ms

Others

Touch Technology: Advanced infrared touch technology
Accuracy: Center 90% touch area: 1mm
Anti-Glare: High transparent+Smooth+Anti-glare
Glass Hardness: 9H (Pencil Hardness); 7(Mohs Hardness) Tempered Glass
Writing Height: ≤ 1mm

CPU

Quad core A73+Quad core A53

GPU

MaliG52 MP8

RAM

8GB

ROM

128GB

Others

Android 14 / Windows 11 (Optional)

HDMI

HDMI OUT x1
HDMI IN (ARC) 1 2. 0 x1
HDMI IN (CEC) 2 2.0 x1

VGA

1x VGA

PC Audio In

1x Audio IN

Audio out

1x Audio OUT

LAN

LAN IN/OUT x2

USB

USB 3.0 x2, USB 2.0 x1, USB 3.0 x2

Touch Output

Touch-USB x2

RS232

1x RS232

Others

Wi-Fi 6: IEEE 802.11 ax/ac/b/g/n (5GHz / 2.4GHz)
BT 5.0: 2.1+EDR / 4.2 / 5.0
ISO / IEC 14443 A; ISO / IEC 14443 B

Dimensions

1483.9 * 86.7 * 911.6mm

Weight

40.5kg

Power

Power Consumption: 178W(typ.)
Operating Power: 100 V ~ 240 V/AC, 50/60 Hz
Standby Consumption: ≤0.5W

Others

Environment
Operating Temperature: 0°C to 40°C
Storage Temperature: 10°C to 60°C
Operating Humidity: 20% to 80% RH (Non-condensing)
Storage Humidity: 10% to 60% RH (Non-condensing)
Color: Blue grey
Case Material: Aluminium Alloy and Sheet Metal

Warranty

1-year
