Operating Conditions

-40°C to 60°C (-40°F to140°F), Humidity: 90% or less (non-condensing)

Power Supply

12 VDC ± 25%

Image Sensor

2 MP CMOS

Electronic Shutter Speed

PAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s

Minimum Illumination

0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR

IR Distance

Up to 20 m IR distance for bright night imaging

Lens Type

2.8 mm, 3.6 mm fixed focal lens

Mount Type

M12

Focal Length

2.8 mm, horizontal FOV: 101°, vertical FOV: 56°, diagonal FOV: 118°
3.6 mm, horizontal FOV: 78°, vertical FOV: 42°, diagonal FOV: 92°

Max Aperture

F1.2

Resolution

1920 × 1080

Day/Night

ICR

Video Interface

Switchable TVI/AHD/CVI/CVBS

Warranty

01 year warranty
