Pan/Tilt/Rotation

Pan: 0° to 360°, tilt: 0° to 180°, rotate 0° to 360°

Operating Conditions

-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

Storage Conditions

-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

Power Supply

12 VDC ± 25%, PoE: 802.3af, Type 1 Class 3, reverse polarity protection

Power Consumption

12 VDC, 0.50 A, max. 6W
PoE (802.3af, 36 V to 57 V), 0.20 A to 0.10 A, max. 7 W

Image Sensor

1/3″ Progressive Scan CMOS

Electronic Shutter Speed

1/3 s to 1/100,000 s

Minimum Illumination

Color: 0.028 Lux @ (F2.0, AGC ON), 0 Lux with IR

S/N Ratio

≥ 52 dB

IR Distance

50 m

Lens Type

4 mm, horizontal FOV 75°, vertical FOV 41°, diagonal FOV 88°
6 mm, horizontal FOV 49°, vertical FOV 26°, diagonal FOV 57°

Mount Type

M12

Max Aperture

4 mm F2.0; 6mm F1.6

Resolution

2560 × 1440

Frame Rate

50Hz: 20fps (2560 × 1440), 25fps (2304 × 1296, 1920 × 1080, 1280 × 720)
60Hz: 20fps (2560 × 1440), 30fps (2304 × 1296, 1920 × 1080, 1280 × 720)

Day/Night

ICR Cut

BLC Mode

Yes

Warranty

1 year
