Fingerprint Capacity

6,000 (1:N) (Standard)

Face Capacity

3,000 (1:N) (Standard)

ID Card Capacity

6,000 (1:N) (Standard)

Display

2.8" @ TFT Color Touch LED Screen (240*320)

Communication

WIFI, TCP/IP x 1, Wiegand (Input or Output) x 1, RS485: ZKTeco RS485 x 1, USB: Type A (USB Drive Only) x 1, Aux Inputs x 1, Electric Lock x 1, Door Sensor x 1, Exit Button x 1, 12V Output x 1

Standard Functions

ADMS, DST, Photo Capture, Event Photo Capture, Up to 14-digit User ID, Access Levels, Groups, Holidays, Anti-Passback, Record Query, Schedule Bell, Tamper Switch Alarm, Automatic Status Switch, Multiple AuthenticationMethods, SIP Client (Version 2.0), ONVIF (Compatible with Profile S, Profile T, Profile G, Profile C, Profile Q & Profile A), AC Push and TA Push Protocol Switch Switch, HTTPs / SSH Backend Access, T9 Keyboard (Input)

Interface

RS485 (RS485 Card Reader / Biometric Reader)

Others

Max. User Password Length: 8 Digits

Biometric Verification Speed:
Less than 0.5 sec (Fingerprint) less than 0.35 sec (Facial Authentication)
Less than 0.35 sec (Facial Authentication)

Touchless Biometric Recognition Distance:
30cm to 200cm (Facial Authentication)

Hardware: CPU: Dual Core@1GHz RAM: 512MB; ROM: 8GB Speaker: 8ohm @1W Microphone: *1 (Sensitivity: -42 dB/ Omni-directional/ Signal-to-Noise Ratio: 58 dB/ Impedance: 2.2kΩ) Supplement Light: No

Dimension

166 x 63 x 25mm

Weight

0.185 Kg

Power Supply

DC 12V 3A

Others

Software: ZKBio CVAccess / ZKBioTime, Mobile App.: ZKBio Zlink / ZSmart, Cloud Service: ZKBio Zlink

Warranty

1 year warranty
