Access Channel

10 channels

Network Bandwidth

90Mbps

Playback Decoding

4ch 8MP@15fps
4ch 5MP@30fps

Video Compression

H.265/H.264

Audio Compression

AAC

Back-up File Format

MP4

Live Display

1,4,8,9,10

Wired Network

1, RJ45 10/100 Mbps self adaptive Ethernet interface

Compatible APP

IMOU APP (IOS Android)

Third Party Agreement

Onvif

Video Output

1*VGA 1*HDMI

Audio Input

1*Microphone(Built in)

Audio Output

1*Speaker(Built in)

USB Interface

2*USB

Reset Button

YES

Network Interface

1 RJ45 port (10/100 Mbps)

IPC Connection

Automatically connect to
IMOU cameras

Smart Detection

Motion /Person / Vehicle

Remote Upgrade

Yes

Sound Channel

Two Way Audio

Power Supply

DC 12V 2A

Power Consumption

＜9W ( with HDD Average
Power)
＜19W ( with HDD Peak
Power

Working Temperature

-10 ℃℃~+45

Working Humidity

Less Than 95%RH

Bare Weight

850g(Without HDD)
