Image Sensor

1/2.7" Progressive Scan CMOS

Effective Pixels

2MP

IR Distance

Up to 30 m

Others

Max. Resolution: 1920 × 1080
Min. Illumination: Color: 0.01 Lux @(F2.0, AGC ON), B/W: 0 Lux with IR
Shutter Time: 1/3 s to 1/100, 000 s
Day & Night: IR cut filter
Angle Adjustment: Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360°

Type

Fixed focal lens

Focal Length

2.8mm

Aperture

F2.0

Angle of View

horizontal FOV 105°, vertical FOV 58°, diagonal FOV 123°

Others

Lens Mount: M12
Iris Type: Fixed

Dimension

Ø110 mm × 93.2 mm (Ø4.3" × 3.7")

Weight

Approx. 320 g (0.7 lb.)

Power

12 VDC ± 25%, 0.4 A, max. 5 W, Ø5.5 mm coaxial power plug
PoE: 802.3af, Class 3, 36 V to 57 V, 0.2 A to 0.15 A, max. 6.5 W

Interface

1 RJ45 10 M/100 M self-adaptive Ethernet port
