Casing

Metal

Dimensions

Ø 210 mm × 344.7 mm (Ø 8.27" × 13.57")

Weight

Approx. 3.0 kg (6.61 lb.)

Pan/Tilt/Rotation

Movement Range (Pan): 360°
Movement Range (Tilt): -15° to 90° (auto flip)
Pan Speed: Pan speed: configurable from 0.1° to 120°/s; preset speed: 120°/s
Tilt Speed: Tilt speed: configurable from 0.1° to 80°/s, preset speed 80°/s

Operating Conditions

-30 °C to 65 °C (-22 °F to 149 °F). Humidity 90% or less (non-condensing)

Power Supply

24 VAC, Max. 24 W (including max. 9 W for IR and max. 1.6 W for heater); PoE (802.3at)

Image Sensor

1/2.8″ Progressive Scan CMOS

Effective Pixels

4MP

Electronic Shutter Speed

1 s to 1/30,000 s

Minimum Illumination

Color: 0.005 Lux @ (F1.6, AGC ON); B/W: 0.001 Lux @ (F1.6, AGC ON), 0 Lux with IR

IR Distance

up to 150 m

Focal Length

4.8 mm

Max Aperture

Max. F1.6

Angle of View

Horizontal field of view: 55° to 2.4° (wide-tele)
Vertical field of view: 33° to 1.4° (wide-tele)
Diagonal field of view: 61.5° to 2.8° (wide-tele)

Focus Control

Auto, semi-auto, manual

Resolution

Main Stream
50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)
60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)

Sub-Stream
50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288)
60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)

Third Stream
50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)
60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)

Day/Night

Day, Night, Auto, Schedule

BLC Mode

Yes

Noise Reduction

Yes

Audio Interface

1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%;
1 output (line out), line level, output impedance: 600 Ω

Features

Ethernet Interface: 1 RJ45 10M/100M self-adaptive Ethernet port
On-board Storage: Built-in memory card slot, support microSD/SDHC/SDXC card, up to 256 GB
Motion detection, video tampering alarm, exception, alarm input and output
