Interface

1 HDMI, 1 VGA

Multi-Screen Display

1/4/8/9

OSD

Camera title, Time, Camera lock, Motion detection, Recording

Resolution

HDMI: 3840×2160, 1920×1080, 1280×1024, 1280×720 VGA: 1920×1080, 1280×1024, 1280×720

brand

Dahua

Trigger Event

Recording, PTZ, Tour, Video Push, Email, Snapshot, Buzzer and Screen Tips

Video Detection

Motion Detection, MD Zones: 396 (22 × 18), Video Loss and Tampering

Alarm Input

4 Channel

Alarm Output

1-Channel relay output,1-Channel 12V control

Ethernet Port

1 Independent 1000Mbps Ethernet Port

Interface

1 RJ-45 Port (10/100/1000Mbps)

Operating Conditions

-10°C ~ +55°C (+14°F ~ +131°F), 86 ~ 106kpa

Operation System

Embedded LINUX

Playback Function

Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Backup Selection, Digital Zoom

PoE

8 ports (IEEE802.3at/af)

Power Consumption

NVR: < 9.6W(without HDD) PoE: Max 25.5w for single port, 130w in total

Power Supply

AC100V ~ 240V, 50 ~ 60 Hz

Records Capacity

2ch@4K 30fps, 8ch@1080P 30fps

Third Party Support

Arecont Vision, Airlive, AXIS, Canon, Dynacolor, JVC, LG, Panasonic, Pelco, PSIA, Samsung, Sanyo, Sony, Watchnet and more

Sync Playback

1/4/9

Main Processor

Quad-core embedded processor

Network Function

HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, DDNS, FTP, SNMP, IP Search (Support IP camera, DVR, NVS, etc.)

Dimension

1U, 375mm×327.5mm×53mm (14.8" x 12.9" x2.1")

Gross Weight

4kg(8.8 lb)(without HDD)

Net Weight

2.6kg (5.7 lb) (without HDD)
